REAR POLY CARRIER SHIFTER BUSHING (FOR: BMW E30, E28, AND E34)

Many people replace the front bushings on the shifter carrier with a harder bushing such as delrin , however, the rear of the carrier is often neglected. Left to fit in the old rotting factory rubber leaving tons of shifter movement! Our rear Garagistic poly carrier bushings replace the original rubber bushing with a hard poly. Simply burn the old one out and press these ones in! (Note: Unlike the delrin versions which requires minor grinding to remove the "lips" of the shifter shaft off, this does not require any modifications). Fits inside 25111220556

If you are running rubber or poly transmission mounts, this is the correct rear shifter carrier bushing for you. If you are running delrin, you can run our delrin or this poly rear carrier bushing.

The reason for this is because the the transmission and shifter cannot have diffrent allowable movements. This will cause linkages to brake, difficulty shifting and other issues. We also offer a delrin version of this bushing for people who run delrin transmission bushings.

WHAT CARS CAN USE THE REAR DELRIN CARRIER SHIFTER BUSHING?

All E28: 528e, 535i, 535is, M5
All E30: 316, 318i, 325, 325e, 325i, 325is, 325ix, M3
E34: 525i, 530i, 535i, M5 (does not fit 540i)

GARAGISTIC DELRIN SHIFTER BUSHINGS INSTRUCTIONS

Here we get into the instructions on how to install your Garagistic Delrin front and rear bushing.

INSTALLATION OF GARAGISTIC DELRIN FRONT CARRIER BUSHING (ROUND).

There is a certain tool that will make your life alot easier when installing these products.

Its a "hook tool" Part number 926572 from Harbor Freight. It can be found here: http://www.harborfreight.com/8-inch-radiator-hose-pick-96572.html . You will use this hook tool to remove the "bitch clip". Buy this tool, it makes the job only take a few seconds.

removal of e30 bitch clip

E30 hook tool

The trans should be supported by the jack,
Lower the jack down until the jack pad is no longer touching the trans then go up slightly to hold it a small amount. you need to do this to allow the bitch clip to rotate back once its unclipped.
With the hook pointed towards the driver side reach above next to the shift carrier and unclip it.

here is a link just for the bitch clip

http://off-camber.net/bitch_clip.php

next is the removal of 1 13mm nut at the rear of the shift carrier.

Now you will have the shift carrier out of the car.
You need to remove the front carrier bushing.
Its a rubber bushing with a metal sleeve.

Use a exacto knife or a razor blade to cut the end of.

Once you cut the sleeve off you can push the rubber to the other side to remove it.

Now your shift carrier should be like this (or similar).

Now you may press the Garagistic front carrier bushing in.

garagistic delrin bushings

If you also bought the rear delrin bushing. The following are the instructions for that.

INSTALLATION INSTRUCTIONS FOR GARAGISTIC REAR DELRIN BUSHING

Installation requres that the edge on the back of the carrier be grinded down a bit.

Before:

After:

You can see the metal file we used in this picture and the Garagistic rear delrin bushing (can be bought here).

Next step is to burn out the old bushing on the rear carrier bracket.

hammer in the new delrin bushing with the chamfered end in first.

Should look like this when its done.

It may be a good idea to "dimple" the metal housings after putting the bushing in.This will ensure that the bushing doesn't slip out the back. Use a punch and hammer for this process.
